| Abs Tone Ring Included |
(Front Left CV Axle Shaft) No |
| Abs Tone Ring Included |
(Front Right CV Axle Shaft) No |
| Abs Tone Ring Included |
(Rear CV Axle Shaft) No |
| Axle Nut Head Type |
(Front Left CV Axle Shaft) Hex |
| Axle Nut Head Type |
(Front Right CV Axle Shaft) Hex |
| Axle Nut Head Type |
(Rear CV Axle Shaft) Hex |
| Axle Nut Height (in) |
(Front Left CV Axle Shaft) 6/7 |
| Axle Nut Height (in) |
(Front Right CV Axle Shaft) 6/7 |
| Axle Nut Height (in) |
(Rear CV Axle Shaft) 1 1/9 |
| Axle Nut Height (mm) |
(Front Left CV Axle Shaft) 21.5 |
| Axle Nut Height (mm) |
(Front Right CV Axle Shaft) 21.5 |
| Axle Nut Height (mm) |
(Rear CV Axle Shaft) 28 |
| Axle Nut Hex Size (in) |
(Front Left CV Axle Shaft) 1 3/7 |
| Axle Nut Hex Size (in) |
(Front Right CV Axle Shaft) 1 3/7 |
| Axle Nut Hex Size (in) |
(Rear CV Axle Shaft) 1 3/7 |
| Axle Nut Hex Size (mm) |
(Front Left CV Axle Shaft) 36 |
| Axle Nut Hex Size (mm) |
(Front Right CV Axle Shaft) 36 |
| Axle Nut Hex Size (mm) |
(Rear CV Axle Shaft) 36 |
| Axle Nut Included |
(Front Left CV Axle Shaft) Yes |
| Axle Nut Included |
(Front Right CV Axle Shaft) Yes |
| Axle Nut Included |
(Rear CV Axle Shaft) Yes |
| Axle Nut Length (in) |
(Front Left CV Axle Shaft) 1 5/8 |
| Axle Nut Length (in) |
(Front Right CV Axle Shaft) 1 5/8 |
| Axle Nut Length (in) |
(Rear CV Axle Shaft) 1 5/8 |
| Axle Nut Length (mm) |
(Front Left CV Axle Shaft) 41.5 |
| Axle Nut Length (mm) |
(Front Right CV Axle Shaft) 41.5 |
| Axle Nut Length (mm) |
(Rear CV Axle Shaft) 41.5 |
| Axle Nut Locking Type |
(Front Left CV Axle Shaft) Self-Lock |
| Axle Nut Locking Type |
(Front Right CV Axle Shaft) Self-Lock |
| Axle Nut Locking Type |
(Rear CV Axle Shaft) Self-Lock |
| Axle Nut Thread Size |
(Front Left CV Axle Shaft) M24*1.5 |
| Axle Nut Thread Size |
(Front Right CV Axle Shaft) M24*1.5 |
| Axle Nut Thread Size |
(Rear CV Axle Shaft) M24*1.5 |
| Boot Material |
(Front Left CV Axle Shaft) Neoprene |
| Boot Material |
(Front Right CV Axle Shaft) Neoprene |
| Boot Material |
(Rear CV Axle Shaft) Neoprene |
| Inboard Bolt Head Size (in) |
(Front Left CV Axle Shaft) 1/3 |
| Inboard Bolt Head Size (in) |
(Front Right CV Axle Shaft) 1/2 |
| Inboard Bolt Head Size (mm) |
(Front Left CV Axle Shaft) 8 |
| Inboard Bolt Head Size (mm) |
(Front Right CV Axle Shaft) 12 |
| Inboard Bolt Head Type |
(Front Left CV Axle Shaft) Allen |
| Inboard Bolt Head Type |
(Front Right CV Axle Shaft) Allen |
| Inboard Bolt Length (in) |
(Front Left CV Axle Shaft) 2 1/6 |
| Inboard Bolt Length (in) |
(Front Right CV Axle Shaft) 2 5/6 |
| Inboard Bolt Length (mm) |
(Front Left CV Axle Shaft) 55 |
| Inboard Bolt Length (mm) |
(Front Right CV Axle Shaft) 72 |
| Inboard Bolt Thread Size |
(Front Left CV Axle Shaft) M10*1.5 |
| Inboard Bolt Thread Size |
(Front Right CV Axle Shaft) M12*1.75 |
| Inboard Joint Type |
(Front Left CV Axle Shaft) Bolt-On |
| Inboard Joint Type |
(Front Right CV Axle Shaft) Bolt-On |
| Inboard Joint Type |
(Rear CV Axle Shaft) Bolt-On |
| Inboard Shaft Connection Style |
(Front Left CV Axle Shaft) Bolt-On |
| Inboard Shaft Connection Style |
(Front Right CV Axle Shaft) Bolt-On |
| Inboard Shaft Connection Style |
(Rear CV Axle Shaft) Bolt-On |
| New Or Remanufactured |
(Front Left CV Axle Shaft) New |
| New Or Remanufactured |
(Front Right CV Axle Shaft) New |
| New Or Remanufactured |
(Rear CV Axle Shaft) New |
| Number Of Inboard Joint Bolt Holes |
(Front Left CV Axle Shaft) 6 |
| Number Of Inboard Joint Bolt Holes |
(Front Right CV Axle Shaft) 6 |
| Number Of Inboard Shaft Bolts |
(Front Left CV Axle Shaft) 6 |
| Number Of Inboard Shaft Bolts |
(Front Right CV Axle Shaft) 6 |
| Number Of Outboard Splines |
(Front Left CV Axle Shaft) 30 |
| Number Of Outboard Splines |
(Front Right CV Axle Shaft) 30 |
| Number Of Outboard Splines |
(Rear CV Axle Shaft) 30 |
| Outboard Joint Type |
(Front Left CV Axle Shaft) Conventional |
| Outboard Joint Type |
(Front Right CV Axle Shaft) Conventional |
| Outboard Joint Type |
(Rear CV Axle Shaft) Conventional |
| Outboard Shaft Connection Style |
(Front Left CV Axle Shaft) Spline |
| Outboard Shaft Connection Style |
(Front Right CV Axle Shaft) Spline |
| Outboard Shaft Connection Style |
(Rear CV Axle Shaft) Conventional |
| Overall Compressed Length (in) |
(Front Left CV Axle Shaft) 20.67 |
| Overall Compressed Length (in) |
(Front Right CV Axle Shaft) 20.71 |
| Overall Compressed Length (in) |
(Rear CV Axle Shaft) 28.94 |
| Overall Compressed Length (mm) |
(Front Left CV Axle Shaft) 525 |
| Overall Compressed Length (mm) |
(Front Right CV Axle Shaft) 526 |
| Overall Compressed Length (mm) |
(Rear CV Axle Shaft) 735 |
