Description
The Brembo 09.5166.1X Brake Rotor is a high quality part designed to provide reliable, efficient braking performance on Volkswagen vehicles. It is precision-drilled and is compatible with part numbers 1HM615301B, 1HM615301E, 321615301D, and 6N0615301D. This part is engineered to provide even and consistent braking power, enabling you to safely and securely stop your car in any conditions. Brembo is a trusted manufacturer for automotive parts, and you can be sure you are getting a quality product when you purchase the 09.5166.1X Brake Rotor. Purchase yours today for the best price on the market.
| Braking Surface | Drilled |
| Centering Diameter (MM) | 65 |
| Fixing Screws | included |
| Height (MM) | 38.7 |
| Material | Grey Cast Iron |
| Minimum Thickness (MM) | 18.5 |
| Nominal Thickness (MM) | 20 |
| Number of Holes | 4 |
| Outside Diameter (MM) | 256 |
| Rust Resistant Coating | UV Coated |
| Solid Or Vented Type Rotor | vented |
| Torque Spec(NM) | 110 |
| Brand | Part # |
|---|
| Brand | Part # |
|---|---|
| Seat | 321615301D |
| Volkswagen | 1HM615301B |
| Volkswagen | 1HM615301E |
| Volkswagen | 321615301D |
| Volkswagen | 6N0615301D |
| Volkswagen | 6NO615301D |
| Brand | Part # |
|---|---|
| Aimco | 3464 |
| ATE | CW20128 |
| Beck/Arnley | 083-2183 / 0832183 |
| Raybestos | 9933 |
| Seat | 321615301D |
| Volkswagen | 1HM615301B |
| Volkswagen | 1HM615301E |
| Volkswagen | 321615301D |
| Volkswagen | 6N0615301D |
| Volkswagen | 6NO615301D |
| Wagner | BD60866 |
| Zimmermann | 600.1597.00 / 600159700 |
